DRILL MAG 8A 120V 1.5"MAX HOUGEN
In stock
Only 4 left
SKU
HOUG-HMD0904101
TTD $9,999.00
The mag drill of choice for fabrication. Lightweight, compact, powerful & versatile.
• Large 1-1/2" x 2" capacity
• Pilot light
• Two stage magnet - 30% power increase when motor is turned on
• Slot Drive arbor for more accuracy and quicker change out of accessories
• Housing - stronger stiffer, more ergonomic
• Positive slug ejection
• Many accessories are available for a portable machine shop including: drill chucks, tapping, countersink, and more...
• Feed handles quickly change from side to side
• Lift detector safety system
• Rear mounted controls
• Gravity feed coolant system (HMD904 w/ coolant bottle)
• Carrying case included
• Two year warranty
Swivel Base adds even greater versatility:
• Precisely line up your pilot with the holes center location
• One stroke lock and unlock handle
• Great for horizontal, overhead, tight areas and getting out over another piece of steel
• Patented
| HMD904 SPECIFICATIONS | |||
| Electrical System | 115V, 50/60 Hz - 9A, 1035W 230V, 50/60 Hz - 4.5A, 1035W | ||
| Motor | 8A (115V), 4 (230V), 450 RPM | ||
| Diameter | 7/16"- 1-1/2" (12mm - 38mm) | ||
| Depth | 2" (50mm) | ||
| Cutter/Mount | "12,000-Series" & Copperhead™ & Fusion™ cutters, 3/4" shank | ||
| Dimensions | 19-5/8" H x 7-3/4" W x 11-5/8" L (499mm H x 197mm W x 295mm L) | ||
| Swivel Area | 1-1/8" W x 1-3/8" L (28.5mm H x 34.9mm W) | ||
| Magnet | Base | 3-1/8" W x 6-9/16" L (79mm W x 167mm L) | |
| 1" Plate(25mm) | Dead Lift 1750 lb. (794 kg) | Drillpoint Breakaway 995 lb. (452 kg) | |
| 3/8" Plate(9.5mm) | 1310 lb. (594 kg) | 710 lb. (322 kg) | |
| Magnet (Swivel) | 1" Plate(25mm) | Dead Lift 1340 lb. (608 kg) | Drillpoint Breakaway For. 695 lb. (315 kg) Back 835 lb. (379 kg) |
| 3/8" Plate(9.5mm) | 1015 lb. (460 kg) | For. 503 lb. (228 kg) Back 605 (274 kg) | |
| Weight | 28.9 lb. (13.1 kg) • Shipping 43 lb (19.5 kg) | ||
| Weight (Swivel) | 31.9 lb. (14.5 kg) • Shipping 45 lb (20.4 kg) | ||
| Shipping Dimensions | 18 x 20 x 9" (45.72 x 50.8 x 22.9 cm) | ||
| HMD904 SPECIFICATIONS | |||
| Electrical System | 115V, 50/60 Hz - 9A, 1035W 230V, 50/60 Hz - 4.5A, 1035W | ||
| Motor | 8A (115V), 4 (230V), 450 RPM | ||
| Diameter | 7/16"- 1-1/2" (12mm - 38mm) | ||
| Depth | 2" (50mm) | ||
| Cutter/Mount | "12,000-Series" & Copperhead™ & Fusion™ cutters, 3/4" shank | ||
| Dimensions | 19-5/8" H x 7-3/4" W x 11-5/8" L (499mm H x 197mm W x 295mm L) | ||
| Swivel Area | 1-1/8" W x 1-3/8" L (28.5mm H x 34.9mm W) | ||
| Magnet | Base | 3-1/8" W x 6-9/16" L (79mm W x 167mm L) | |
| 1" Plate(25mm) | Dead Lift 1750 lb. (794 kg) | Drillpoint Breakaway 995 lb. (452 kg) | |
| 3/8" Plate(9.5mm) | 1310 lb. (594 kg) | 710 lb. (322 kg) | |
| Magnet (Swivel) | 1" Plate(25mm) | Dead Lift 1340 lb. (608 kg) | Drillpoint Breakaway For. 695 lb. (315 kg) Back 835 lb. (379 kg) |
| 3/8" Plate(9.5mm) | 1015 lb. (460 kg) | For. 503 lb. (228 kg) Back 605 (274 kg) | |
| Weight | 28.9 lb. (13.1 kg) • Shipping 43 lb (19.5 kg) | ||
| Weight (Swivel) | 31.9 lb. (14.5 kg) • Shipping 45 lb (20.4 kg) | ||
| Shipping Dimensions | 18 x 20 x 9" (45.72 x 50.8 x 22.9 cm) | ||
| SKU | HOUG-HMD0904101 |
|---|---|
| Weight | 55.000000 |
| Manufacturer | HOUGEN |
