PUMP FUEL TRANSF & NOZZLE "12V/DC 20GPM HOSE 1""X12
In stock
Only 5 left
SKU
FRT-FR4210H
TTD $5,859.00
PRODUCT FEATURES
Durable cast iron pump housing built to withstand the wear and tear of rough operating environments
Removable junction box allows for easier installation
Thermal overload protection prevents motor from overheating during abnormal usage
Pump is capable of pumping fluid out of an 8 ft. deep storage tank (at sea level)
Rugged switch lever is designed to endure heavy abuse
Self-priming pump with a 1/4 HP motor at 2,600 RPM (30 minute on/off duty cycle)
Durable cast iron pump housing built to withstand the wear and tear of rough operating environments
Removable junction box allows for easier installation
Thermal overload protection prevents motor from overheating during abnormal usage
Pump is capable of pumping fluid out of an 8 ft. deep storage tank (at sea level)
Rugged switch lever is designed to endure heavy abuse
Self-priming pump with a 1/4 HP motor at 2,600 RPM (30 minute on/off duty cycle)
INCLUDES
(1) FILL-RITE 12-Volt 20 GPM 1/4 HP Fuel Transfer Pump (Manual Nozzle Package)
PRODUCT DESCRIPTION
The FR4210H is a 12-Volt 20 GPM fuel transfer pump that comes with a 1 in. x 12 ft. discharge hose, 1 in. manual nozzle, 1 in. x 34 in. telescoping steel suction pipe, 1 in. elbow, 5 ft. 12-Gauge ground wire, and a 18 ft. 12-Gauge 2-wire battery cable. It can be used to pump gasoline, diesel, kerosene, ethanol blends up to 15%, methanol blends up to 15%, and bio-diesel up to B20. The previous FR4210G model has been updated to the FR4210H model. With a removable junction box, the product is now easier to install. The performance specifications of the product did not change.
TECHNICAL SPECIFICATIONS
Product Depth (in.): 11 in
Product Height (in.): 10 in
Product Width (in.): 14 in
Amperage (A): 20 A
Cord Length (ft.): 18 ft
Discharge Flow @ 0 ft. (gallons/hour): 1200
Discharge Flow @ 0 ft. (gallons/min): 20
Discharge Flow @ 10 ft. (gallons/hour): 1200
Discharge Flow @ 10 ft. (gallons/min): 20
Features: Self-Priming, Thermal Overload Protection
Head Pressure (ft.): 37
Housing Material: Cast-Iron
Impeller Material: Steel
Included: Hardware
Inlet Connection: Threaded female
Maximum Discharge Flow (gallons/hour): 1200
Maximum Horsepower (hp): 1/4
Maximum Pressure (PSI): 16 PSI
Maximum Working Temperature (F): 105
Minimum working temperature (F): -13
Outlet Connection: Threaded female
Pack Size: 1
Power Type: Electric
Power Type Required: DC
Item Weight (lb.): 29 lb
Pump Switch Type: Electronic
Vertical Lift (ft.): 37
Voltage: 12v
Shipping Weight: 30lbs
(1) FILL-RITE 12-Volt 20 GPM 1/4 HP Fuel Transfer Pump (Manual Nozzle Package)
PRODUCT DESCRIPTION
The FR4210H is a 12-Volt 20 GPM fuel transfer pump that comes with a 1 in. x 12 ft. discharge hose, 1 in. manual nozzle, 1 in. x 34 in. telescoping steel suction pipe, 1 in. elbow, 5 ft. 12-Gauge ground wire, and a 18 ft. 12-Gauge 2-wire battery cable. It can be used to pump gasoline, diesel, kerosene, ethanol blends up to 15%, methanol blends up to 15%, and bio-diesel up to B20. The previous FR4210G model has been updated to the FR4210H model. With a removable junction box, the product is now easier to install. The performance specifications of the product did not change.
TECHNICAL SPECIFICATIONS
Product Depth (in.): 11 in
Product Height (in.): 10 in
Product Width (in.): 14 in
Amperage (A): 20 A
Cord Length (ft.): 18 ft
Discharge Flow @ 0 ft. (gallons/hour): 1200
Discharge Flow @ 0 ft. (gallons/min): 20
Discharge Flow @ 10 ft. (gallons/hour): 1200
Discharge Flow @ 10 ft. (gallons/min): 20
Features: Self-Priming, Thermal Overload Protection
Head Pressure (ft.): 37
Housing Material: Cast-Iron
Impeller Material: Steel
Included: Hardware
Inlet Connection: Threaded female
Maximum Discharge Flow (gallons/hour): 1200
Maximum Horsepower (hp): 1/4
Maximum Pressure (PSI): 16 PSI
Maximum Working Temperature (F): 105
Minimum working temperature (F): -13
Outlet Connection: Threaded female
Pack Size: 1
Power Type: Electric
Power Type Required: DC
Item Weight (lb.): 29 lb
Pump Switch Type: Electronic
Vertical Lift (ft.): 37
Voltage: 12v
Shipping Weight: 30lbs
| SKU | FRT-FR4210H |
|---|---|
| Weight | 30.000000 |
| Manufacturer | FILL-RITE |
