INVERTER MULTISYS 250A MIG-ARC-TIG WHEELED

In stock

Only 12 left

SKU

JTA-KUMJRRW250K

TTD $10,999.00

The RAZORWELD 250K is an inverter-based multifunction MIG welding machine with added Stick and TIG function. The MIG function allows you to weld with both Gas Shielded and Gasless wire applications. Easy stepless adjustment of voltage and wire feed make for easy setting of welding parameters giving excellent, professional welding results.

PRODUCT FEATURES

Latest IGBT inverter technology
MIG/MAG with Gas and Gasless wire function
Spool Gun connection
Stick Function
DC TIG welding with Lift Arc start
Wire Inch & Burn Back control
Industrial application
Internal wire feeder, gear driven
10Lbs to 33Lbs Spools
Euro style MIG torch connection
IP21S rating for environmental/safety protection
Stepless voltage and wire feed control
Excellent MIG welding with CO2 gas & mixed gas
Excellent arc stability for MIG/TIG/STICK welding
Designed and built to our specification. Certified to – AS/NZ60974-1

PACKAGE CONTENTS
1 x RAZORWELD 250K Power Source
1 x 15ft Tweco 2 Style MIG Torch
1 x 12 ft Arc Welding lead set including twist lock electrode holder & 300 Amp earth clamp
1 x Razorflow Argon Regulator
1 x 6.5ft Gas Hose with connections
1 x Instruction Manual

Color

PRODUCT DESCRIPTION

The RAZORWELD 250K is the ideal machine for light to medium industrial and panel work . The machine is single phase 230V and also portable and perfect for workshop use. The MIG function provides superb arc characteristics when using either Gas Shielded or Gasless Wires. The machine features an adjustable Burnback control and easy to use panel layout to get your job done faster.

The machine is also a very capable MMA (Stick) welder capable of running most MMA Electrodes up to 5/32. An added feature of Hot Start helps when striking an Arc to minimize the Electrode sticking to the workpiece.

With the machine being Spool Gun ready a RAZORWELD Spool Gun is available if you want to run Aluminium wire without the changeover in the torch, liner and drive roller. The Spool Gun is an ideal way to use softer wires and not have to purchase larger spools of wire for small jobs.

The RAZORWELD 250K is also a DC TIG welder with Lift Arc function. DC TIG will allow welding of materials such as Mild and Stainless Steels as well as Bronze, Copper and Chrome Moly’s.

*Always refer to the recommended polarity setup as stated on the electrode packaging.

Optional Accessories:
WP17V35/50 TIG Torch
19ft 200 Amp Spool Gun

TECHNICAL SPECIFICATIONS

Part NumberJRW250K
Primary Input Voltage230V ±15% - 1 Phase
Rated Input Power KVA11 KVA MIG / 13 KVA Stick
ieff AMPS27.8 A MIG / 31.5A Stick
Rated Output MIG30A/15.5V - 250A/26.5V
Rated Output Stick10A/20.4V - 250A/30.0V
Welding Current Range10 - 250 Amps
Duty Cycle 104° Deg F - MIG35% @ 250 Amps
Duty Cycle 104° Deg F - TIG35% @ 250 Amps
Duty Cycle 104° Deg F - Stick35% @ 250 Amps
Dimensions (in)35 x 12 x 25
Weight Power Source (Lbs)104
Shipping Weight 140 lbs.
